B A R C H E T T A   E N G I N E

This 4 cylinder 1747cc engine has been build especially for the barchetta. It roots stem from the Lancia Kappa 1998cc 5 cylinder engine which was the base of a whole family of Fiat/Lancia/Alfa Romeo engines.

Fiat has a brand-new plant called F.M.A. (Fabrica Motori Automobili) in Pratola Serra (near Napoli), where every 10 minutesa new engine is build. It used to be the production line of the Alfa Arna, but has been converted into a engine production facility since October '93.


Technical data
4 Cylinders with each 4 valves and 1 coil (Hitachi)
Double overhead cam with variable inlet-valve timing
Cylinder block: Cast iron
Cylinder head: Aluminum alloy
Compression ratio: 10.3 ± 0.15 to 1
Bore × stroke: 82 × 82.7 mm
Max power @ 6300 rpm: 96 kW / 130 bhp (unless tuned)
Max torque @ 4300 rpm: 164 Nm / 121 lb ft
Max number of revs (redline): 7150 rpm (injectors will be cut-off one-by-one in "1-4-3-2"-sequence)
Specific output: 55 kW / 74,4 bhp per liter
Power to weight: 109 bph per ton
Engine weight: 146 kg / 322 lb
Injection: Hitachi MFI-0 sequential phased multipoint system (3 bar, 120 liter/h)
Noise production (100 km/h): 73.0 dB(A)
Noise production (120 km/h): 76.5 dB(A)


Explanation of some engine procedures
Speed table
km/h secondsmph seconds
0-402.8 0-404.4
0-60 4.3 0-50 6.4
0-80 6.3 0-60 8.7
0-100 8.9 0-70 11.6
0-120 12.4 0-9019.9
0-140 16.7 0-100 26.3
60-100 9.2 in 4th
13.2 in 5th
30-50 5.3 in 3rd
7.8 in 4th
11.2 in 5th
60-120 14.0 in 4th
20.3 in 5th
50-70 10.5 in 5th
200 topspeed 124 topspeed
Speed at 1000 rpm in highest gear: 32.3 km/h / 20.1 mph
Standing ¼ mile: 16.1 secs / 84 mph

5 second video driving the German Autobahn (540kb)
15 second video doing 0-100 km/h (1.3Mb)

Go to the gearstick for more figures.
